The Completer Handbook to gain a fundamental understanding of electric motors and the other ele- . cy of 75% we can expect the small electric motor. Rotor currents and torque – small slip. Rotor currents . for non-specialist users and students of electric motors and drives. My original aim was the more prosaic 'handbooks', which are full of useful detail but provide little opportunity for . aug section 1: introduction electric handbook motors small - wordpress of small electric motors book by mcgraw hill professional ebook pdf at our library.

One is to use a kind of electric current that periodically reverses direction, which is known as an alternating current AC. In the kind of small, battery-powered motors we use around the home, a better solution is to add a component called a commutator to the ends of the coil. Don't worry about the meaningless technical name: this slightly old-fashioned word "commutation" is a bit like the word "commute". It simply means to change back and forth in the same way that commute means to travel back and forth.

In its simplest form, the commutator is a metal ring divided into two separate halves and its job is to reverse the electric current in the coil each time the coil rotates through half a turn.

One end of the coil is attached to each half of the commutator.

The electric current from the battery connects to the motor's electric terminals. With the commutator in place, when electricity flows through the circuit, the coil will rotate continually in the same direction.

Artwork: A simplified diagram of the parts in an electric motor. Animation: How it works in practice. Note how the commutator reverses the current each time the coil turns halfway.

This means the force on each side of the coil is always pushing in the same direction, which keeps the coil rotating clockwise. A simple, experimental motor such as this isn't capable of making much power. We can increase the turning force or torque that the motor can create in three ways: either we can have a more powerful permanent magnet, or we can increase the electric current flowing through the wire, or we can make the coil so it has many "turns" loops of very thin wire instead of one "turn" of thick wire.

In practice, a motor also has the permanent magnet curved in a circular shape so it almost touches the coil of wire that rotates inside it. The closer together the magnet and the coil, the greater the force the motor can produce.

Although we've described a number of different parts, you can think of a motor as having just two essential components: There's a permanent magnet or magnets around the edge of the motor case that remains static, so it's called the stator of a motor.

Inside the stator, there's the coil, mounted on an axle that spins around at high speed—and this is called the rotor. The rotor also includes the commutator. Universal motors DC motors like this are great for battery-powered toys things like model trains, radio-controlled cars, or electric shavers , but you don't find them in many household appliances. Small appliances things like coffee grinders or electric food blenders tend to use what are called universal motors, which can be powered by either AC or DC.

Unlike a simple DC motor, a universal motor has an electromagnet, instead of a permanent magnet, and it takes its power from the DC or AC power you feed in: When you feed in DC, the electromagnet works like a conventional permanent magnet and produces a magnetic field that's always pointing in the same direction.

The commutator reverses the coil current every time the coil flips over, just like in a simple DC motor, so the coil always spins in the same direction. When you feed in AC, however, the current flowing through the electromagnet and the current flowing through the coil both reverse, exactly in step, so the force on the coil is always in the same direction and the motor always spins either clockwise or counter-clockwise.

Electric motor

What about the commutator? The frequency of the current changes much faster than the motor rotates and, because the field and the current are always in step, it doesn't actually matter what position the commutator is in at any given moment.

Animation: How a universal motor works: The electricity supply powers both the magnetic field and the rotating coil. With a DC supply, a universal motor works just like a conventional DC one, as above. With an AC supply, both the magnetic field and coil current change direction every time the supply current reverses. That means the force on the coil is always pointing the same way. Photo: Inside a typical universal motor: The main parts inside a medium-sized motor from a coffee grinder, which can run on either DC or AC.

The gray electromagnet round the edge is the stator static part and its powered by the orange-colored coils. Two independent multiphase winding sets i. Doubly-fed electric motors are machines with an effective constant torque speed range that is twice synchronous speed for a given frequency of excitation. This is twice the constant torque speed range as singly-fed electric machines , which have only one active winding set. A doubly-fed motor allows for a smaller electronic converter but the cost of the rotor winding and slip rings may offset the saving in the power electronics components.

Difficulties with controlling speed near synchronous speed limit applications. Nothing in the principle of any of the motors described above requires that the iron steel portions of the rotor actually rotate. If the soft magnetic material of the rotor is made in the form of a cylinder, then except for the effect of hysteresis torque is exerted only on the windings of the electromagnets. Taking advantage of this fact is the coreless or ironless DC motor , a specialized form of a permanent magnet DC motor.

The rotor can take the form of a winding-filled cylinder, or a self-supporting structure comprising only the magnet wire and the bonding material.

The rotor can fit inside the stator magnets; a magnetically soft stationary cylinder inside the rotor provides a return path for the stator magnetic flux. A second arrangement has the rotor winding basket surrounding the stator magnets. In that design, the rotor fits inside a magnetically soft cylinder that can serve as the housing for the motor, and likewise provides a return path for the flux. Because the rotor is much lighter in weight mass than a conventional rotor formed from copper windings on steel laminations, the rotor can accelerate much more rapidly, often achieving a mechanical time constant under one ms.

This is especially true if the windings use aluminum rather than the heavier copper. But because there is no metal mass in the rotor to act as a heat sink, even small coreless motors must often be cooled by forced air.

Overheating might be an issue for coreless DC motor designs. Modern software, such as Motor-CAD , can help to increase the thermal efficiency of motors while still in the design stage. The vibrating alert of cellular phones is sometimes generated by tiny cylindrical permanent-magnet field types, but there are also disc-shaped types that have a thin multipolar disc field magnet, and an intentionally unbalanced molded-plastic rotor structure with two bonded coreless coils.

Metal brushes and a flat commutator switch power to the rotor coils. Related limited-travel actuators have no core and a bonded coil placed between the poles of high-flux thin permanent magnets.

These are the fast head positioners for rigid-disk "hard disk" drives. Although the contemporary design differs considerably from that of loudspeakers, it is still loosely and incorrectly referred to as a "voice coil" structure, because some earlier rigid-disk-drive heads moved in straight lines, and had a drive structure much like that of a loudspeaker.

The printed armature or pancake motor has the windings shaped as a disc running between arrays of high-flux magnets. The magnets are arranged in a circle facing the rotor with space in between to form an axial air gap.

The technology has had many brand names since its inception, such as ServoDisc. The printed armature originally formed on a printed circuit board in a printed armature motor is made from punched copper sheets that are laminated together using advanced composites to form a thin rigid disc.

The printed armature has a unique construction in the brushed motor world in that it does not have a separate ring commutator. The brushes run directly on the armature surface making the whole design very compact.

An alternative manufacturing method is to use wound copper wire laid flat with a central conventional commutator, in a flower and petal shape. The windings are typically stabilized with electrical epoxy potting systems. These are filled epoxies that have moderate, mixed viscosity and a long gel time. The unique advantage of ironless DC motors is the absence of cogging torque variations caused by changing attraction between the iron and the magnets.

Parasitic eddy currents cannot form in the rotor as it is totally ironless, although iron rotors are laminated. These motors were originally invented to drive the capstan s of magnetic tape drives, where minimal time to reach operating speed and minimal stopping distance were critical.

Pancake motors are widely used in high-performance servo-controlled systems, robotic systems, industrial automation and medical devices. Due to the variety of constructions now available, the technology is used in applications from high temperature military to low cost pump and basic servos. Another approach Magnax is to use a single stator sandwiched between two rotors. This yokeless axial flux motor offers a shorter flux path, keeping the magnets further from the axis.

The design allows zero winding overhang; percent of the windings are active. This is enhanced with the use of rectangular-section copper wire. The motors can be stacked to work in parallel.

Electricity, magnetism, and movement

Instabilities are minimized by ensuring that the two rotor discs put equal and opposing forces onto the stator disc. The rotors are connected directly to one another via a shaft ring, cancelling out the magnetic forces. Magnax motors range in size from. A servomotor is a motor, very often sold as a complete module, which is used within a position-control or speed-control feedback control system. Servomotors are used in applications such as machine tools, pen plotters, and other process systems.

Motors intended for use in a servomechanism must have well-documented characteristics for speed, torque, and power. The speed vs. Dynamic response characteristics such as winding inductance and rotor inertia are also important; these factors limit the overall performance of the servomechanism loop.

Large, powerful, but slow-responding servo loops may use conventional AC or DC motors and drive systems with position or speed feedback on the motor. As dynamic response requirements increase, more specialized motor designs such as coreless motors are used. AC motors' superior power density and acceleration characteristics compared to that of DC motors tends to favor permanent magnet synchronous, BLDC, induction, and SRM drive applications.

A servo system differs from some stepper motor applications in that the position feedback is continuous while the motor is running. A stepper system inherently operates open-loop—relying on the motor not to "miss steps" for short term accuracy—with any feedback such as a "home" switch or position encoder being external to the motor system. As long as power is on, a bidirectional counter in the printer's microprocessor keeps track of print-head position. Stepper motors are a type of motor frequently used when precise rotations are required.

In a stepper motor an internal rotor containing permanent magnets or a magnetically soft rotor with salient poles is controlled by a set of external magnets that are switched electronically. A stepper motor may also be thought of as a cross between a DC electric motor and a rotary solenoid. As each coil is energized in turn, the rotor aligns itself with the magnetic field produced by the energized field winding.

Unlike a synchronous motor, in its application, the stepper motor may not rotate continuously; instead, it "steps"—starts and then quickly stops again—from one position to the next as field windings are energized and de-energized in sequence. Depending on the sequence, the rotor may turn forwards or backwards, and it may change direction, stop, speed up or slow down arbitrarily at any time. Simple stepper motor drivers entirely energize or entirely de-energize the field windings, leading the rotor to "cog" to a limited number of positions; more sophisticated drivers can proportionally control the power to the field windings, allowing the rotors to position between the cog points and thereby rotate extremely smoothly.

This mode of operation is often called microstepping. Computer controlled stepper motors are one of the most versatile forms of positioning systems, particularly when part of a digital servo-controlled system.

As drive density increased, the precision and speed limitations of stepper motors made them obsolete for hard drives—the precision limitation made them unusable, and the speed limitation made them uncompetitive—thus newer hard disk drives use voice coil-based head actuator systems. The term "voice coil" in this connection is historic; it refers to the structure in a typical cone type loudspeaker. This structure was used for a while to position the heads. Modern drives have a pivoted coil mount; the coil swings back and forth, something like a blade of a rotating fan.

Nevertheless, like a voice coil, modern actuator coil conductors the magnet wire move perpendicular to the magnetic lines of force. Stepper motors were and still are often used in computer printers, optical scanners, and digital photocopiers to move the optical scanning element, the print head carriage of dot matrix and inkjet printers , and the platen or feed rollers.

Likewise, many computer plotters which since the early s have been replaced with large-format inkjet and laser printers used rotary stepper motors for pen and platen movement; the typical alternatives here were either linear stepper motors or servomotors with closed-loop analog control systems.

So-called quartz analog wristwatches contain the smallest commonplace stepping motors; they have one coil, draw very little power, and have a permanent magnet rotor. The same kind of motor drives battery-powered quartz clocks.

Fleming's Left-Hand Rule

Some of these watches, such as chronographs, contain more than one stepping motor. Closely related in design to three-phase AC synchronous motors, stepper motors and SRMs are classified as variable reluctance motor type. A linear motor is essentially any electric motor that has been "unrolled" so that, instead of producing a torque rotation , it produces a straight-line force along its length.

Linear motors are most commonly induction motors or stepper motors. Linear motors are commonly found in many roller-coasters where the rapid motion of the motorless railcar is controlled by the rail. They are also used in maglev trains , where the train "flies" over the ground.

On a smaller scale, the era HP A pen plotter used two linear stepper motors to move the pen along the X and Y axes. The fundamental purpose of the vast majority of the world's electric motors is to electromagnetically induce relative movement in an air gap between a stator and rotor to produce useful torque or linear force. According to Lorentz force law the force of a winding conductor can be given simply by:.

The most general approaches to calculating the forces in motors use tensors. Where rpm is shaft speed and T is torque , a motor's mechanical power output P em is given by, [95]. For a linear motor, with force F expressed in newtons and velocity v expressed in meters per second,. In an asynchronous or induction motor, the relationship between motor speed and air gap power is, neglecting skin effect , given by the following:.

Since the armature windings of a direct-current or universal motor are moving through a magnetic field, they have a voltage induced in them. This voltage tends to oppose the motor supply voltage and so is called " back electromotive force emf ". The voltage is proportional to the running speed of the motor.

The back emf of the motor, plus the voltage drop across the winding internal resistance and brushes, must equal the voltage at the brushes. This provides the fundamental mechanism of speed regulation in a DC motor. If the mechanical load increases, the motor slows down; a lower back emf results, and more current is drawn from the supply. This increased current provides the additional torque to balance the new load.

In AC machines, it is sometimes useful to consider a back emf source within the machine; as an example, this is of particular concern for close speed regulation of induction motors on VFDs. Motor losses are mainly due to resistive losses in windings, core losses and mechanical losses in bearings, and aerodynamic losses, particularly where cooling fans are present, also occur. Losses also occur in commutation, mechanical commutators spark, and electronic commutators and also dissipate heat.

To calculate a motor's efficiency, the mechanical output power is divided by the electrical input power:.

It is possible to derive analytically the point of maximum efficiency. Various regulatory authorities in many countries have introduced and implemented legislation to encourage the manufacture and use of higher-efficiency electric motors. Eric Laithwaite [97] proposed a metric to determine the 'goodness' of an electric motor: From this, he showed that the most efficient motors are likely to have relatively large magnetic poles.

However, the equation only directly relates to non PM motors. All the electromagnetic motors, and that includes the types mentioned here derive the torque from the vector product of the interacting fields. For calculating the torque it is necessary to know the fields in the air gap. Once these have been established by mathematical analysis using FEA or other tools the torque may be calculated as the integral of all the vectors of force multiplied by the radius of each vector.

The current flowing in the winding is producing the fields and for a motor using a magnetic material the field is not linearly proportional to the current.

This makes the calculation difficult but a computer can do the many calculations needed. Once this is done a figure relating the current to the torque can be used as a useful parameter for motor selection. The maximum torque for a motor will depend on the maximum current although this will usually be only usable until thermal considerations take precedence.

When optimally designed within a given core saturation constraint and for a given active current i. Some applications require bursts of torque beyond the maximum operating torque, such as short bursts of torque to accelerate an electric vehicle from standstill. Always limited by magnetic core saturation or safe operating temperature rise and voltage, the capacity for torque bursts beyond the maximum operating torque differs significantly between categories of electric motors or generators.

Capacity for bursts of torque should not be confused with field weakening capability. Field weakening allows an electric machine to operate beyond the designed frequency of excitation.

Field weakening is done when the maximum speed cannot be reached by increasing the applied voltage.

This applies to only motors with current controlled fields and therefore cannot be achieved with permanent magnet motors. Electric machines without a transformer circuit topology, such as that of WRSMs or PMSMs, cannot realize bursts of torque higher than the maximum designed torque without saturating the magnetic core and rendering any increase in current as useless.

Furthermore, the permanent magnet assembly of PMSMs can be irreparably damaged, if bursts of torque exceeding the maximum operating torque rating are attempted. Electric machines with a transformer circuit topology, such as induction machines, induction doubly-fed electric machines, and induction or synchronous wound-rotor doubly-fed WRDF machines, exhibit very high bursts of torque because the emf-induced active current on either side of the transformer oppose each other and thus contribute nothing to the transformer coupled magnetic core flux density, which would otherwise lead to core saturation.

Electric machines that rely on induction or asynchronous principles short-circuit one port of the transformer circuit and as a result, the reactive impedance of the transformer circuit becomes dominant as slip increases, which limits the magnitude of active i.

Still, bursts of torque that are two to three times higher than the maximum design torque are realizable. The brushless wound-rotor synchronous doubly-fed BWRSDF machine is the only electric machine with a truly dual ported transformer circuit topology i. If a precision means were available to instantaneously control torque angle and slip for synchronous operation during motoring or generating while simultaneously providing brushless power to the rotor winding set, the active current of the BWRSDF machine would be independent of the reactive impedance of the transformer circuit and bursts of torque significantly higher than the maximum operating torque and far beyond the practical capability of any other type of electric machine would be realizable.

Torque bursts greater than eight times operating torque have been calculated. The continuous torque density of conventional electric machines is determined by the size of the air-gap area and the back-iron depth, which are determined by the power rating of the armature winding set, the speed of the machine, and the achievable air-gap flux density before core saturation.

Despite the high coercivity of neodymium or samarium-cobalt permanent magnets, continuous torque density is virtually the same amongst electric machines with optimally designed armature winding sets. Continuous torque density relates to method of cooling and permissible period of operation before destruction by overheating of windings or permanent magnet damage. Other sources state that various e-machine topologies have differing torque density.

One source shows the following: Torque density is approximately four times greater for electric motors which are liquid cooled, as compared to those which are air cooled.

Another source notes that permanent-magnet synchronous machines of up to 1 MW have considerably higher torque density than induction machines. The continuous power density is determined by the product of the continuous torque density and the constant torque speed range of the electric machine. The latter source, which can be responsible for the "whining noise" of electric motors, is called electromagnetically-excited acoustic noise.

An electrostatic motor is based on the attraction and repulsion of electric charge. Usually, electrostatic motors are the dual of conventional coil-based motors. They typically require a high-voltage power supply, although very small motors employ lower voltages. Conventional electric motors instead employ magnetic attraction and repulsion, and require high current at low voltages.

In the s, the first electrostatic motors were developed by Benjamin Franklin and Andrew Gordon. Today, the electrostatic motor finds frequent use in micro-electro-mechanical systems MEMS where their drive voltages are below volts, and where moving, charged plates are far easier to fabricate than coils and iron cores. Also, the molecular machinery that runs living cells is often based on linear and rotary electrostatic motors.

A piezoelectric motor or piezo motor is a type of electric motor based upon the change in shape of a piezoelectric material when an electric field is applied. Piezoelectric motors make use of the converse piezoelectric effect whereby the material produces acoustic or ultrasonic vibrations to produce linear or rotary motion. An electrically powered spacecraft propulsion system uses electric motor technology to propel spacecraft in outer space, most systems being based on electrically powering propellant to high speed, with some systems being based on electrodynamic tethers principles of propulsion to the magnetosphere.

From Wikipedia, the free encyclopedia. For other kinds of motors, see Motor disambiguation. For a railroad engine, see Electric locomotive. Main article: History of the electric motor. Rotor electric. Commutator electric. DC motor. Brushed DC electric motor. Permanent-magnet electric motor. Brushless DC electric motor. Switched reluctance motor. Universal motor. AC motor. Induction motor. Torque motor. Synchronous motor.

Doubly-fed electric machine. Servo motor. Stepper motor. Linear motor. This section needs expansion. You can help by adding to it. March Electromotive force. Goodness factor. This section only describes one highly specialized aspect of its associated subject. Please help improve this article by adding more general information.

The talk page may contain suggestions. Main articles: Electrostatic motor , Piezoelectric motor , and Electrically powered spacecraft propulsion.

Electronics portal Energy portal Electric motors portal. Single-phase — straight and compensated series motors, railway motor; three-phase — various repulsion motor types, brush-shifting series motor, brush-shifting polyphase shunt or Schrage motor, Fynn-Weichsel motor. Quarterly Journal of Science, Literature and the Arts. Royal Institution of Great Britain. Retrieved 12 February The Scots Colleges Abroad: Jefimenko Early Electric Motors.

Archived from the original on 6 March Archived from the original on 20 July McMillan and Co. Archived from the original on Norman Lockyer. Magnetism A Very Short Introduction.

Handbook of small electric motors

Oxford University Press. Archived from the original PDF on 14 September Retrieved 13 February Elektrisiermaschinen im Jahrhundert — Ein kleines Lexikon "Electrical machinery in the 18th and 19th centuries — a small thesaurus" in German.

University of Regensburg. Archived from the original on June 9, Retrieved August 23, June 9, Archived from the original on May 12, Archived from the original on 2 March Elektrotechnischen Instituts. Karlsruhe Institute of Technology. Retrieved 14 May Oxford Dictionary of National Biography. A History of Engineering and Technology: Artful Methods 2nd ed.

Electric motors

CRC Press. Retrieved May 7, Electrifying America: Social Meanings of a New Technology. The MIT Press. Archived from the original on 26 August Invent Now, Inc. Hall of Fame profile. Retrieved Elementary Treatise in Physics.

Atkinson 14th ed. William Wood and Co. Louis motor".

Archived PDF from the original on January Philosophical Transactions of the Royal Society. Retrieved 2 December Philosophical Magazine. Archived from the original on December 1, The Serbian Journal of Electrical Engineers. Archived PDF from the original on 4 July Retrieved 10 February Empires of Light: Random House. Atti della R. Academia delle Science di Torino. Nikola Tesla. The Franklin Institute. Archived from the original on 18 November Edison Tech Center.

Archived from the original on 1 August Retrieved 3 July Creating the Twentieth Century: Technical Innovations of — and Their Lasting Impact. Volume 17 — Television Technology. Archived from the original on 3 March Retrieved 10 October Control Techniques Drives and Controls Handbook. Institution of Electrical Engineers.
