As the name tells everything, a linear circuit means linear characteristics in between Current and Voltage, which means, current flowing through a circuit is directly proportional to the applied Voltage.

If we increase the applied voltage, then the current flowing through the circuit will also increase, and vice versa. If we draw the circuit output characteristic curve in between Current and Voltage, it will look like a straight line Diagonal as shown in fig 1.

But this is not always the case.

In a linear circuit, the output response of the circuit is directly proportional to the input. Simple Explanation of the above statement is,.

A nonlinear circuit is an electric circuit whose parameters are varied with respect to Current and Voltage. In other words, an electric circuit in which circuit parameters Resistance, inductance, capacitance, waveform, frequency etc is not constant, is called Non Linear Circuit.

If we draw the circuit output characteristic curve in between Current and Voltage, it will look like a curved or bending line as shown in fig 2. Solving of a nonlinear circuit is a little bit complex then linear circuits. Linear circuit can be solved with simple techniques and scientific calculator.

While solving Non linear circuits, a lot of data and information is required. But nowadays, due to aggressive technological changes and Modernization, we can simulate and analyze, with output curves both linear and non linear circuits very easily with the help of circuit simulation tools like PSpice , MATLAB, Multisim etc.
