For this reason, it is often informally described as operating at Layer 2. MPLS was created in the late s as a more efficient alternative to traditional IP routing, which requires each router to independently determine a packet's next hop by inspecting the packet's destination IP address before consulting its own routing table.
This process consumes time and hardware resources, potentially resulting in degraded performance for real-time applications such as voice and video. In an MPLS network, the very first router to receive a packet determines the packet's entire route upfront, the identity of which is quickly conveyed to subsequent routers using a label in the packet header.
While router hardware has improved exponentially since MPLS was first developed -- somewhat diminishing its significance as a more efficient traffic management technology-- it remains important and popular due to its various other benefits, particularly security, flexibility and traffic engineering.
Sandwiched between Layers 2 and 3, a label is a four-byte -- bit -- identifier that conveys the packet's predetermined forwarding path in an MPLS network. FEC is a group of packets with similar characteristics that are forwarded in the same manner over the same path and with the same forwarding treatment.
This is the router where the MPLS process starts.
Also known as the transit router, the LSRs are routers that lie along a label switched path established by LERs between a source and destination pair. The LSR then removes the current label and replaces swaps it with a new label based on the path and forwards the packet to the next LSR.
This is the most basic concept of MPLS.
While there are multiple modes by which this is done, the common modes are downstream on demand, also known as solicited mode, and unsolicited mode. In downstream on demand or solicited mode, the upstream LER sends out an LDP label request to the next hop router determined from the routing table. The request is forwarded by each hop till it reaches the egress router and a return message that confirms the LSP is generated.
In unsolicited mode, which is the most common mode, an LSR router broadcasts label mappings to all neighbors. The broadcasts are spread through the network till they reach the upstream or ingress routers that can then establish an LSP.
This is usually performed by LSRs between the ingress and egress routers. Pop: Removes a label.
This is most often done by the egress router. This diagram illustrates how a simple MPLS network works.
